Compliant with SFP-DD/SFP+ MSA Standard
Compliant with SFF 8431/ SFF 8432 Standard
Compliant with IEEE 802.3ba (10GBASE-CR) Standard
Data Rate: 10G NRZ Per Channel
Low Power Consumption
Cost-effective Copper Solution
Management Interface follows SFF-8472 Standard and can be customized
Excellent SI Performance
Custom Colors For Pull Tab
Market and Application
High-Performance Computing (HPC)
Network Interface Cards (NIC's)
Data Center and Enterprise Storage Systems
Telecommunication Equipment
10Gbps Ethernet
InfiniBand? 1X QDR/ FDR
Fibre Channel
Mechanical Performance
SFP28 Module
Module Insertion: 18N Maximum
Module Extraction: 12.5N Maximum
Latch Retention: 90N Minimum-170N Maximum
Rated Durability Cycles: 50 Cycles Minimum
Electrical Performance
SFP+ Module
Supply Voltage 3.3 VDC +/- 5%
Supply Current:0.03A Max at 3.135V
Power Consumption (DAC) : 0.125 Watt Max
Voltage: 30VAC per contact
Current: 0.5A/Signal Contact
Signal Integrity
IEEE 802.3ba (10GBASE-CR)
InfiniBand? 1X QDR(40G)/FDR(56G)
Product Environmental Compliance
1. RoHS2.0: Compliant
2. China RoHS: Yes
3. REACH SVHC: Yes
4. Low-Halogen Products: Optional
