Part Details
Product Specification
ITEM | Description |
Connector | SATA 7Pin connector |
Connector Contact | SAS connector as defined in SFF-8482 |
Connector Configuration | 29-Pin Connector |
Connector Termination Style | Right Angel |
No. of HSIO Routed | Surface Mount |
RF Co-axial Launch Connector | 2 TX and 2 RX |
HSIO Routing | 2.92mm Connector -50 Ohm |
Board Stack-Up | 50 Ohm ±5% Single-Ended Stripline |
De-embedding structure | 4 Layers (1.52mm thickness) |
Reference plane for 2X THRU De-embedding structure | 2X THRU Line |
Power source to DUT | 40mils from void |
